CJ3M-CPU12
CPU, 10K steps program, 32K words data memory, 32K words x 1 bank EM, 5120 I/O max, RS-232C serial port, USB-C programming port, 7 expansion racks max.
Specifications
| Program capacity | 10 K steps |
| Data memory capacity | 64 K words |
| Logic execution time | 0.04 µs |
| Max. number of expansion units | 80 |
| Max. number of local I/O points | 5120 |
| Number of built-in digital I/Os | 0 |
| Communication port(s) | Serial RS-232C, USB |
| Product Height (unpacked) | 90 mm |
| Product Width (unpacked) | 31 mm |
| Product Depth (unpacked) | 75 mm |
| Product Weight (unpacked) | 0 g |
Tilbehør
| CJ1W-PA202 | Power supply unit, 100-240 VAC, output capacity: 14 W |
|
|
| CJ1W-PA205R | Power supply unit, 100-240 VAC, output capacity: 25 W, with RUN output |
|
|
| CJ1W-PD022 | Power supply unit, 24 VDC, output capacity: 19.6 W |
|
|
| CJ1W-PD025 | Power supply unit, 24 VDC, output capacity: 25 W |
|
