NC MECHATROLINK-II

Multi-axis point-to-point positioning controller over MECHATROLINK-II Motion Bus

NC MECHATROLINK-II is a powerful controller for point-to-point applications. It is based on MECHATROLINK-II Motion Bus, which reduces programming and development and maintenance costs. Supports PLC Open Function Blocks.

  • Position control units with 2, 4 or 16 axes
  • High-speed bus MECHATROLINK-II is specially designed for motion control
  • Supports position, speed and torque control
  • Programming languages: ladder, function blocks. Supports PLC Open Function Blocks
  • Smart active parts for Omron HMI terminals reduce engineering time
  • Access to the complete system from one point. Network setup, servo drives configuring and monitoring, and PLC programming

Specifications & ordering info

Ordering information

Position controller unit

Name

Order code

MECHATROLINK-II position controller unit - 16 axes

CJ1W-NCF71

MECHATROLINK-II position controller unit - 4 axes

CJ1W-NC471

MECHATROLINK-II position controller unit - 2 axes

CJ1W-NC271

MECHATROLINK-II related devices

Servo system

Name

Order code

Accurax G5 servo drive ML-II built-in

R88D-KN ___ -ML2

G-Series servo drive ML-II built-in

R88D-GN __ H-ML2

Note: Refer to servo systems section for detailed specs and ordering information

MECHATROLINK-II cables

Name

Remarks

Order code

MECHATROLINK-II terminator

Terminating resistor

JEPMC-W6022

MECHATROLINK-II cables

0.5 meter

JEPMC-W6003-A5

1 meter

JEPMC-W6003-01

3 meters

JEPMC-W6003-03

5 meters

JEPMC-W6003-05

10 meters

JEPMC-W6003-10

20 meters

JEPMC-W6003-20

30 meters

JEPMC-W6003-30

Computer software

Specifications

Order code

CX-One version 2.0 (CX-Motion NCF 1.70 or higher)

CX-One version 3.0 (CX-Motion NCF 1.90 or higher)

CX-One version 4.0 or higher

CX-One
